JET-1000

‌Please scroll left and right for full information

ITEM \ MODEL	JET-1000
Table working surface (mm)	1200 x 600(47.2"x23.6")
Longitudinal travel(X) (mm)	1020(40.2")
Cross travel(Y) (mm)	610(24")
Vertical travel(Z) (mm)	500(19.7")
Spindle nose to table (mm)	100~600(3.9"~23.6")
Spindle center to slideway (mm)	180(7.1")
Spindle taper	BBT-40 (Std.) / HSK A63(Opt.)
Spindle speed (rpm)	60~15000 direct drive spindle (Std.) 15000 / 18000 / 20000 built-in spindle (Opt.)
Spindle motor (kW)	7.5 / 11 direct drive spindle (Std.) 17/21 built-in spindle (Opt.)
X-Y-Z Rapid traverse (m / min)	40 / 40 / 24
Cutting feed rate (mm / min)	1~12000
Tool selection	Bi-direction, Change tools in the shortest distance
No. of tools	24 tools for Arm type(Std.) 32 tools or more for Arm type(Opt.)
Max. tool diameter Adjacent pockets Max. tool dia (mm)	75( ∅3")
Max. tool diameter without adjacent tools (mm)	100( ∅4")
Max. tool length (mm)	300(11.8")
Max. tool weight (kg)	10 (22 Ib)
Table load capacity (kg)	800(1760 Ib)
Machine weight (kg)	8000(17600 Ib)
Machine dimensions (L x W x H) (mm)	3140 x 2912 x 2910 (123.6"x114.6"x114.6")
Cutting capacity(S45C) - milling (cc / min)	240
Cutting capacity(S45C) - drilling (mm)	∅30
Cutting capacity(S45C) - tapping	M30 x P3.5

Standard Accessories

Fanuc 0i-MF PLUS: a.10.4” LCD b.Manual Guide i c.Die & mold high-speed machining package
External coolant supply system with spindle nozzles
Spindle air blast
Screw type chip conveyors with buckets
LED working lights
3-color signal tower
Liquid cooling system for direct drive spindle
Heat exchangers for electric cabinet
40-tool ATC
Full enclosure with interlocks system
Complete set of machine manuals in English
1 pc of toolbox for basic maintenance
Foundation bolts and levelling pads
Automatic centralized lubrication system for ball screws and guideways with alarms
